ALLIED ELECTRONICS NeXGen User Manual

NeXGen  Gilbarco/Bennett - Installation and Start Up Guide
Copyright  2018 by Allied Electronics, Inc.
October 18, 2018 Page
2-9
2.3.1 Gilbarco Pump and CRIND Communication
Up to 16 fueling positions may be connected to the NeXGen on each dispenser
communications channel (CH5 and CH6). Up To 32 CRINDs may be connected to the
NeXGen on CH7. Each port must have a 2-wire custom cable which terminates in
either a 2 pin male CPC (circular plastic connector), a female DB-9 connector or a
RJ45 connector.
Pump Control  NeXGen CH5 and CH6 to Gilbarco D-Box
CRIND Control  NeXGen CH7 to Gilbarco Universal D-Box
(1) Circular Plastic Connector
NeXGen (CH5 or CH6) RJ45 adapter to Gilbarco (CPC)
NeXGen
RJ45
Pins
CAT 5 Cable
(T568B Spec.)
RJ45
Modular Jack
Pins
Gilbarco
Circular Connector
Pins
- 6
--------------
Wht/Grn
--------------
3 (Blk)
2 -
+ 7
--------------
Blue
--------------
4 (Red)
1 +
(2) DB-9 Connectors
NeXGen (CH5, CH6 or CH7) RJ45 adapter to Gilbarco (DB9 Female)
(Part #N9323B-ADP “Pump” / Part #N9323C-ADP “CRIND)
NeXGen
RJ45
Pins
CAT 5 Cable
(T568B Spec.)
RJ45
Modular Jack
Pins
Gilbarco
DB9 Female
Pins
- 6
--------------
Green
--------------
6 (Yel)
6 -
+ 7
--------------
Wht/Brn
--------------
7 (Brn)
7 +
