ALLIED ELECTRONICS NeXGen User Manual

NeXGen  Gilbarco/Bennett - Installation and Start Up Guide
Copyright  2018 by Allied Electronics, Inc.
October 18, 2018 Page
2-11
2.3.3 Bennett Dispenser Communication
Up to 16 fueling positions may be connected to the dispenser communication Channel (11).
They will connect to NeXGen via the Bennett Distribution box.
NeXGen (CH11) RJ45 adapter to Bennett D-box
(Part #N9301B-ADP)
NeXGen
RJ45
Pins
CAT 5 Cable
(T568B Spec.)
RJ45
Adapter
Pins
Bennett
D-box
Screw terminal
Signal GND 3
--------------
Wht/Grn
--------------
3 (Blk)
Signal GND
RS485 (-) 4
--------------
Blue
--------------
4 (Red)
RS485 (-)
Drain 5
--------------
Wht/Blu
--------------
5 (Grn)
Drain
RS485 (+) 8
--------------
Brown
--------------
8 (Wht)
RS485 (+)
2.3.4 Bennett/Verifone CAT Communication
Up to 16 Bennett or Verifone CATs may be connected to the card reader communication Channel
(12). They will connect to NeXGen via the Bennett Distribution box.
NeXGen (CH12) RJ45 adapter to Bennett D box
(Part #N9301V-ADP)
NeXGen
RJ45
Pins
CAT 5 Cable
(T568B Spec.)
RJ45
Adapter
Pins
Bennett
D-box
Screw terminal
Signal GND 3
--------------
Wht/Grn
--------------
3 (Blk)
Signal GND
RS485 (-) 4
--------------
Blue
--------------
4 (Red)
RS485 (-)
Drain 5
--------------
Wht/Blu
--------------
5 (Grn)
Drain
RS485 (+) 8
--------------
Brown
--------------
8 (Wht)
RS485 (+)
