ALLIED ELECTRONICS NeXGen User Manual

NeXGen  Gilbarco/Bennett - Installation and Start Up Guide
Copyright  2018 by Allied Electronics, Inc.
October 18, 2018 Page
2-19
2.3.7.5 Kesseltronics Advanced dual bay via the MUX PAP isolator box
NeXGen (CH 3) RJ45 adapter to the Kesseltronics
“Advanced Dual bay” via MUX PAP isolator box /DB9
(Part #N9352-ADP)
NeXGen
RJ45
Pins
CAT 5 Cable
(T568B Spec.)
RJ45
Adapter
Pins
Kesseltronics ADB
DB9 Female
Pins
RXD 3
--------------
Wht/Grn
--------------
3 (Blk)
3 TXD
TXD 5
--------------
Wht/Blu
--------------
5 (Grn)
2 RXD
GND 8
--------------
Brown
--------------
8 (Wht)
5 GND
NeXGen (CH 3) RJ45 adapter to the Kesseltronics
“Advanced Dual bay” via MUX PAP isolator box /RJ45
NeXGen
RJ45
Pins
CAT 5 Cable
(T568B Spec.)
Kesseltronics ADB
RJ45
Pins
RXD 3
--------------
Wht/Grn
--------------
3 TXD
TXD 5
--------------
Wht/Blu
--------------
2 RXD
GND 8
--------------
Brown
--------------
4 GND
