ALLIED ELECTRONICS NeXGen User Manual

NeXGen  Gilbarco/Bennett - Installation and Start Up Guide
Copyright  2018 by Allied Electronics, Inc.
October 18, 2018 Page
2-15
2.3.6.4 Omntec
NeXGen (CH 2) RJ45 adapter to the OMNTEC OEL 8000 II
NeXGen
RJ45
Pins
CAT 5 Cable
(T568B Spec.)
RJ45
Adapter
Pins
OMNTEC
DB9 Female
Pins
RXD 3
--------------
Wht/Grn
--------------
3 (Blk)
2 TXD
TXD 5
--------------
Wht/Blu
--------------
5 (Grn)
3 RXD
GND 8
--------------
Brown
--------------
8 (Wht)
5 GND
2.3.6.5 OPW EECO
NeXGen (CH 2) RJ45 adapter to the OPW EECO #1500, 2000, 3000
(Part #N9396-ADP)
NeXGen
RJ45
Pins
CAT 5 Cable
(T568B Spec.)
RJ45
Adapter
Pins
EECO
DB9 Male
Pins
RXD 3
--------------
Wht/Grn
--------------
3 (Blk)
3 TXD
RTS 4
--------------
Blue
--------------
4 (Red)
8 CTS
TXD 5
--------------
Wht/Blu
--------------
5 (Grn)
2 RXD
GND 8
--------------
Brown
--------------
8 (Wht)
5 GND
