2.3.8.4 Skyline Fuel Price Sign
NeXGen (CH-RS232) RJ45 adapter to the Skyline Fuel Price Sign
(Part #N9446-ADP)
NeXGen
RJ45
Pins
CAT 5 Cable
(T568B Spec.)
RJ45
Modular Jack
Pins
POS
DB9 Male
Pins
DSR 2
--------------
Orange
--------------
2 (Org)
6 DTR
RXD 3
--------------
Wht/Grn
--------------
3 (Blk)
2 TXD
RTS 4
--------------
Blue
--------------
4 (Red)
7 CTS
TXD 5
--------------
Wht/Blu
--------------
5 (Grn)
3 RXD
CTS 6
--------------
Green
--------------
6 (Yel)
8 RTS
DTR 7
--------------
Wht/Brn
--------------
7 (Brn)
4 DSR
GND 8
--------------
Brown
--------------
8 (Wht)
5 GND
