NeXGen Gilbarco/Bennett - Installation and Start Up Guide
Copyright 2018 by Allied Electronics, Inc.
October 18, 2018 Page
3-1
3 Programming
3.1 Gilbarco Addressing
3.1.1 Gilbarco CRIND Jumper Settings
The following is a list of the jumper settings for the Gilbarco Advantage Series CRINDs.
Jumper Description Setting
JP1 Watchdog Installed
JP14 GEN/MOC Installed
JP 16 Spare Input Installed- Sets the baud rate for the
CRIND to 4800.
JP13 Side A When appropriate
JP11 Cold Start Installed on initial startup.
The CRIND will prompt for this to be
removed after a complete cold start.
JP4 - JP8 CRIND Address Set for the appropriate address- one
behind the pump address.
ex: FP #1, C/R 0, etc.
