ALLIED ELECTRONICS NeXGen User Manual

NeXGen  Gilbarco/Bennett - Installation and Start Up Guide
Copyright  2018 by Allied Electronics, Inc.
October 18, 2018 Page
2-16
2.3.6.6 Incon Tank Sentinel
NeXGen (CH 2) RJ45 adapter to the Incon Tank Sentinel
(Part #N9389-ADP)
NeXGen
RJ45
Pins
CAT 5 Cable
(T568B Spec.)
RJ45
Adapter
Pins
Incon/Comm 1
DB9 Male
Pins
RXD 3
--------------
Wht/Grn
--------------
3 (Blk)
2 TXD
TXD 5
--------------
Wht/Blu
--------------
5 (Grn)
3 RXD
GND 8
--------------
Brown
--------------
8 (Wht)
5 GND
2.3.6.1 TS-550EVO
NeXGen (CH2) RJ45 adapter to the TS-550EVO
(Part #N9449-ADP)
NeXGen
RJ45
Pins
CAT 5 Cable
(T568B Spec.)
RJ45
Modular Jack
Pins
TS
DB9 Female
Pins
RXD 3
--------------
Wht/Grn
--------------
3 (Blk)
2 TXD
RTS 4
--------------
Blue
--------------
4 (Red)
8 CTS
TXD 5
--------------
Wht/Blu
--------------
5 (Grn)
3 RXD
CTS 6
--------------
Green
--------------
6 (Yel)
7 RTS
GND 8
--------------
Brown
--------------
8 (Wht)
5 GND
DSR 2
--------------
Orange
--------------
2 (Org)
Tie to Brown
DTR 7
--------------
Wht/Brn
--------------
7 (Brn)
Tie to Orange
