ALLIED ELECTRONICS NeXGen User Manual

NeXGen  Gilbarco/Bennett - Installation and Start Up Guide
Copyright  2018 by Allied Electronics, Inc.
October 18, 2018 Page
3-8
3.1.6 Bennett Dispenser and Card reader Addressing
Channel (11) has been designated to communicate with the Bennett dispensers. This
Channel can accommodate up to 16 fueling positions. The address of the first fueling
position on Channel 15 will be set to address “1”, the second to address “2” etc.
Channel (12) has been designated to communicate with the Bennett or Verifone CAT.
This Channel can accommodate up to 16 CATs. The address of the first fueling
position on Channel 15 will be set to address “1”, the second to address “2” etc.
Bennett
Pump
Bennett/Verifone
CAT
Fueling
Position
NeXGen
Channel
NeXGen
Channel
1 CH-11 CH-12
2 CH-11 CH-12
3 CH-11 CH-12
4 CH-11 CH-12
5 CH-11 CH-12
6 CH-11 CH-12
7 CH-11 CH-12
8 CH-11 CH-12
9 CH-11 CH-12
10 CH-11 CH-12
11 CH-11 CH-12
12 CH-11 CH-12
13 CH-11 CH-12
14 CH-11 CH-12
15 CH-11 CH-12
16 CH-11 CH-12
