NeXGen Gilbarco/Bennett - Installation and Start Up Guide
Copyright 2018 by Allied Electronics, Inc.
October 18, 2018 Page
3-3
3.1.3 Gilbarco Dispenser, CRIND and OPW OPT Addressing
Two Channels (5 and 6) have been designated to communicate with the Gilbarco dispensers. Each
channel can accommodate up to 16 fueling positions. The address of the first fueling position on
Channel 5 will be set to address “1”, the second to address “2” etc. If Channel 6 is used, the address of
the first fueling position connected on these Channels will also be set to address “1”, the second to
address “2” etc. See example.
The NeXGen controller uses Channel 7 to communicate with the Gilbarco CRINDS. The CRIND device
address must be one less than the fueling position number.
The NeXGen controller uses channel 8 to communicate with the OPW OPT. Up to 16 OPT’s can be supported
and software Version 18.01A, or newer, must be installed. The OPT uses decimal address 32 – 47.
Fueling Position CRIND Address OPT
Fueling
Position
Address NeXGen
Channel
Advantage/
E300
Encore
500
NeXGen
Channel OPT
NeXGen
Channel
1 1 CH-5 0 (no JMP) 32 CH-7 32 CH-8
2 2 CH-5 1 1 CH-7 33 CH-8
3 3 CH-5 2 2 CH-7 34 CH-8
4 4 CH-5 3 3 CH-7 35 CH-8
5 5 CH-5 4 4 CH-7 36 CH-8
6 6 CH-5 5 5 CH-7 37 CH-8
7 7 CH-5 6 6 CH-7 38 CH-8
8 8 CH-5 7 7 CH-7 39 CH-8
9 9 CH-5 8 8 CH-7 40 CH-8
10 10 CH-5 9 9 CH-7 41 CH-8
11 11 CH-5 10 10 CH-7 42 CH-8
12 12 CH-5 11 11 CH-7 43 CH-8
13 13 CH-5 12 12 CH-7 44 CH-8
14 14 CH-5 13 13 CH-7 45 CH-8
15 15 CH-5 14 14 CH-7 46 CH-8
16 16 CH-5 15 15 CH-7 47 CH-8
17 1 CH-6 16 16 CH-7
18 2 CH-6 17 17 CH-7
19 3 CH-6 18 18 CH-7
20 4 CH-6 19 19 CH-7
21 5 CH-6 20 20 CH-7
22 6 CH-6 21 21 CH-7
23 7 CH-6 22 22 CH-7
24 8 CH-6 23 23 CH-7
25 9 CH-6 24 24 CH-7
26 10 CH-6 25 25 CH-7
27 11 CH-6 26 26 CH-7
28 12 CH-6 27 27 CH-7
29 13 CH-6 28 28 CH-7
30 14 CH-6 29 29 CH-7
31 15 CH-6 30 30 CH-7
32 16 CH-6 31 31 CH-7
To Next Page
