NeXGen Gilbarco/Bennett - Installation and Start Up Guide
Copyright 2018 by Allied Electronics, Inc.
October 18, 2018 Page
3-4
3.1.4 Gilbarco Blending Dispensers
Gilbarco Variable Blenders
The NeXGen interfaces to the following Gilbarco variable blenders:
3+0 4+0 5+0
3+1 4+1 5+1
A variable blender without diesel, or 3+0, will have position 1, grade 1 on the left on both
sides of the pump. Gilbarco products are mapped as positions 1, 3 and 5 (Advantage) and
positions 1, 2 and 3 (Advantage with “Optimized” electronics), Low grade, Mid grade and High
grade respectively, from left to right when facing each side of the dispenser. A 5+0 will have
the products mapped as positions 1, 2, 3, 4 and 5. Low grade, blend grade 1, blend grade 2,
blend grade 3 and High grade. The following is an example of a 3+0.
An advantage variable blender with diesel, or 3 + 1, will always have the diesel product for
each side mirrored with one another. The diesel will be on the right when facing side A,
while diesel will be on the left when facing side B. Gilbarco maps the diesel product as
product 6. The remaining grades are mapped the same as the 3 + 0 described above. The
pump is shown below:
B side
product 3
position 5
position 3
product 2
position 3
position 2
product 1
position 1
position 1
Advantage
Adv. w/ optimized & Encore
A side
product 1
position 1
position 1
product 2
position 3
position 2
product 3
position 5
position 3
Advantage
Adv. w/ optimized & Encore
B Side
product 3
position 5
position 3
product 2
position 3
position 2
product 1
position 1
position 1
product 4
position 6
position 6
Advantage
Adv. w/ optimized & Encore
A Side
product 1
position 1
position 1
product 2
position 3
position 2
product 3
position 5
position 3
product 4
position 6
position 6
Advantage
Adv. w/ optimized & Encore
