General
1 - 2
Unit Identifi cation
Allied Winch S/N Nameplate Data For Tractor Mountings
Figure 1-2 Tractor or Skidder Identifi cation Codes and Available Gear Ratios
C
O
D
E
A
New Holland
& Fiat
C
Caterpillar
E
John Deere
H
Dressta
K
Komatsu
R
Case
47
850J

D61EX-15

48
750J

81
D6N

H6G H 1 B 1501 C81
Vehicle Code
Sequence Number
Internal Options
Winch Model
Hydraulic Operation Type
Gear Ratio Code
1 = 60:1
2 = 75:1
3 = 70:1
4 = 88:1
H = High Performance:
Winch Direction Valve, Variable or 2 Speed.
T = Rescue:
Tractor Direction Valve, Single Speed.
See Figure 1-2
B = External Pump, PFR, FS,
BRAKE-OFF Cluch
E = External Pump, PFR, FS
(Early Units Had Hydraulic BRAKE-OFF
Where Motor Rotated)
J = External Pump, PFR, FS;
with CARC Green Paint &
50mm Dia Pin Drawbar;
without Tractor Side Installation Parts
1. In addition to the serial number plate,
the serial number is stamped on the top
left-hand side of the frame.
2. Circled numbers in Figure 1-2 indicate
possible gear ratios.
Notes:
H6G was previously known as WH6G.
The "W" designation has been dropped for simplicity.
