Allied Systems Allied H6G Series User Manual

Section 1
1 - 5
Figure 1-7 Torque Specifi cations
ITEM
TORQUE VALUES
ft-lbs. N-m kg-m
Housing Covers (1/2 UNC Gr. 8) 80 108 11
Drum Shaft Assembly
Drum Adapter to Drum Capscrews (5/8 UNF Gr. 8)
Bearing Retainer Capscrews (1/2 UNF Gr. 8)
155
90
210
122
22
12
Motor Shaft Gear Retainer Capscrews (3/8 UNC Gr. 8)
3-Port Manifold to Motor Capscrews (7/16 UNC Gr. 8)
Directional Manifold Mounting Capscrews (3/8 UNC Gr. 8)
33
52
33
44
71
44
4
7
4
Torque Specifi cations
