Repairs
4 - 38
6. Reinstall cover plate.
2. Install the reducer mounting, gear retainer, spacer
and seal ring in the reducer.
3. Install new O-rings on reducer mounting.
4. Install planetary reducer assembly.
5. Install manifold support bracket in frame.
1. Install new O-rings on seal ring.
- Motor Shaft Assembly & Installation
