Section 4
4 - 27
1. Remove capscrews (item 18) and washers (item 17)
from cover (item 15). Thrust washer (item 14) usually
remains with cover (item 15).
2. Lift sun gear (item 13) from carrier assembly (item
12).
3. Remove carrier assembly (item 12) from ring gear
(item 11).
4. Pull ring gear (item 11) from remaining assembly.
NOTE: It may be necessary to strike ring gear
with a rubber mallet to loose from hub.
5. Remove retaining ring (item 10) from groove in out-
put shaft (item 1). Lift thrust washer (item 9) from
assembly. Pull output shaft (item 1) from hub (item
6). NOTE: To remove retaining ring, use retaining
ring expander tool.
6. Remove oil seal (item 2) and bearing cones (items 3
& 8) from hub (item 6). Inspect bearing cups (items 4
& 7) in hub (item 6) and remove only if replacement
is required.
