83
Chapter 6
Cabling the Stacking Ports
This chapter contains the procedure for cabling the S1 and S2 stacking
slots on the switches with AT-SP10TW stacking transceivers.
To cable the switches of the stack, perform the following procedure:
A transceiver can be damaged by static electricity. Be sure to
observe all standard electrostatic discharge (ESD) precautions, such
as wearing an antistatic wrist strap, to avoid damaging the device.
E77
1. Remove the dust plug from the S1 slot on the top switch of the stack,
as shown in Figure 37.
Figure 37. Removing the Dust Plug from the S1 Slot
2. Remove the transceiver from its shipping container and store the
packaging material in a safe location.
3. Remove the dust cap from one end of the transceiver, as shown in
Figure 38 on page 84.
