WTEC II ELECTRONIC CONTROLS TROUBLESHOOTING MANUAL
E–2 Copyright © 1998 General Motors Corp.
APPENDIX E — CONNECTOR PART NUMBERS, TERMINAL PART
NUMBERS, TOOL PART NUMBERS, AND REPAIR INSTRUCTIONS
LIST OF SPECIAL TOOLS REQUIRED TO SERVICE WTEC II WIRING HARNESSES
Tool Number Tool Type Paragraph Reference
23046604 Splice, Sealed (14–16 AWG) 1–14
23046605 Splice, Sealed (18–22 AWG) 1–14
J 25070 Heat Gun 1–14
J 34182 Crimper 1–8, 1–9, 1–11
J 34513 Remover 1–8
J 34823 Remover 1–7
J 35123 Crimper (alternate) 1–2, 1–3
J 35606 Crimper (alternate) 1–6
J 35615 Wire Stripper 1–14
J 35689-A Remover 1–2, 1–3
J 38125-6 Crimper 1–5, 1–6
J 38125-7 Crimper 1–2, 1–3, 1–4, 1–5, 1–7, 1–12, 1–13
J 38125-8 Crimper 1–12
J 38125-10 Remover 1–6
J 38125-13 Remover 1–4, 1–5, 1–12, 1–13
J 38582-3 Remover 1–8
J38687 Crimper 1–1
J 38852 Crimper (alternate) 1–6
J 39227 Remover 1–1
J 39841 Terminal Remover/Installer (MD Retarder) 1–9
J 39842 Terminal Remover/Installer (MD 3070 T-case) 1–9
J 41193 Connector Repair Kit (FMTV) 1–9
J 41193-1 Guide Pin 1–9
J 41193-2 Insertion Tool 1–9
J 41193-3 Terminal Remover 1–9
J 41194 Extractor/Inserter 1–8
None 50–70 Percent Tin Resin Core Solder 1–10
None Pen-Type Soldering Iron (Max OD = 3.175 mm) 1–10
None Desoldering Braid 1–10
