Allison B 300 - Code 24 XX - Sump Fluid Temperature

Copyright © 1998 General Motors Corp. 6–39
WTEC II ELECTRONIC CONTROLS TROUBLESHOOTING MANUAL
Figure 6–10. Code 24 Schematic Drawing (Units Produced Prior To 9/94)
F 3
ANALOG GROUND
(TPS LO)
SUMP TEMP
ECU
B
A
G 2
GREEN
B 1
B 13
VIOLET
C
135 A
135 B
F 3
SUMP
TEMP
SENSOR
TPS
147
FEEDTHROUGH
CONNECTOR
TRANSMISSION
G 2
A
B
C
G 2
F 3
B 1
B 13
ECU
V01601
B
(BLACK)
SEE NOTE
NOTE: These wires may pass through a bulkhead connector.
CODE 24 XX — SUMP FLUID TEMPERATURE
