Allison B 300 - Code 32 XX - C3 Pressure Switch; Input Functions

Copyright © 1998 General Motors Corp. 6–49
WTEC II ELECTRONIC CONTROLS TROUBLESHOOTING MANUAL
Figure 6–15. Code 32 Schematic Drawing (Units Produced Prior To 9/94)
FOR INPUT FUNCTIONS
SIGNAL GROUND
C 3
F 2
C 3
TRANSMISSION
F 2
161A YELLOW
162 WHITE
ECU
B 27
C3 PS B 28
13
C3
PRESSURE
SWITCH
SIGNAL GROUND
VIW
CONNECTOR
161B
B 28
B 27
F 2
C 3
B
A
13
V04922
ON SWITCH
ON HARNESS
ECU
B
A
B
(BLACK)
SEE NOTE
NOTE: These wires may pass through a bulkhead connector.
CODE 32 XX — C3 PRESSURE SWITCH
