Allison B 300 - Page 86

6–50 Copyright © 1998 General Motors Corp.
WTEC II ELECTRONIC CONTROLS TROUBLESHOOTING MANUAL
Figure 6–16. Code 32 Schematic Drawing (Units Produced 9/94–12/97)
FOR INPUT FUNCTIONS
SIGNAL GROUND
N
W
X
TRANSMISSION
135 GREEN
161 YELLOW
162 WHITE
ECU
B 1
B 27
C3 PS B 28
13
C3
PRESSURE
SWITCH
ANALOG GROUND
SIGNAL GROUND
VIW
CONNECTOR
161 B
TID1
B 28
B 27
B
A
13
V04923
ON SWITCH
ON HARNESS
ECU
B
A
B
(BLACK)
SEE NOTE
NOTE: These wires may pass through a bulkhead connector.
CODE 32 XX — C3 PRESSURE SWITCH
