0180036-J0 Rev E Page 15
LED’s: System OK (Green)
Power System Minor Alarm (Yellow)
Power System Major/Critical Alarm / Controller Fail (Red)
Internal Battery: 3V Lithium CR2032
Audio: Built-in speaker for alarm tones
Mounting: 3U 19/23” Rack Mounting
DIN Rail Mounting
Panel Mounting
Dimensions: CXC HP: 84mm H x 161mm W x 50mm D (3.3" x H x 6.33" W x 1.96" D)
Rack Mount: 131mm H x 431mm W x 100mm D (5.1" x H x 16.9" W x 3.9"
D)
Weight: CXC HP: 500 grams (1.10 lb.)
Rack Mount: 6.2 kg (13.8 lb.)
Communication Ports: 2x Ethernet port,
2x CAN (bus),
2x USB Host
Relay Controller-fail alarm relay contacts (Form C NO / NC)
L-ADIO
Front Panel Controls: Recessed reset button
LED’s: Communication established (Green), Power (Blue)
Mounting: 3RU 19/23” Rack Mounting
DIN Rail Mounting - option
Panel Mounting- option
Dimensions: 84mm H x 200mm W x 30mm D (3.3" x H x 7.87" W x 1.18" D)
Table 2: Specifications: 3RU Rack Mount CXC HP (Continued) (Sheet 3 of 4)
Cordex Controller Panel/Rack Mount
