CHASSIS SECTION (1/2) PARTS LIST
Mark No. Description Part No.
1 USBA Assy DWX4332
2 USBB Assy DWX4333
3 USBP Assy DWX4334
4 AIN Assy DWX4364
5 HPJK Assy DWX4337
6 HPJM Assy DWX4338
7 MTRM Assy DWX4348
8 FGP2 Assy DWX4349
9 CCB1 Assy DWX4410
10 FGP1 Assy DWX4395
11 SNRT1 Assy DWX4355
12 SNRT2 Assy DWX4356
13 SNRT3 Assy DWX4357
14 Crimp Connector PF10PP-D07
15 Crimp Connector PF06PP-S15
16 Connector Assy PF03PP-D30
17 Shielded Conn-Cable DDA1095
18 Shielded Conn-Cable DDA1096
19 Shielded Conn-Cable DDA1061
20 FFC DDD1956
21 Shielded Conn-Cable DDA1097
22 Shielded Conn-Cable DDA1098
23 Shielded Conn-Cable DDA1099
24 Stay DNG1120
25 Stay DNF1951
26 Cover DNF2066
27 Shield Plate DNG1119
28 Stay DNG1125
29 Stay DNF2069
30 Stay DNF1958
31 Stay DNG1122
32 Shield Plate DNG1140
33 Shield Case DNG1127
34 Locking Mini Clamp DEC2439
35 Holder VEC1355
36 Sheet DEC3621
37 Cable Tie ZCA-SKB90BK
38 EMC Gasket DEC3637
39 EMC Gasket DEC3638
40 Cord Clamper (Steel) RNH-184
41 • • • • •
42 • • • • •
43 Nut (M12) NKX2FNI
44 Nut M12 DBN1018
45 Washer DEC2920
46 Screw BBZ30P060FTC
47 Screw BPZ30P080FTB
48 Screw PPZ30P080FTB
