It is necessary to remove UCOM Assy to diagnose CUEVR Assy.
LEDs diagnosis of CUEVR Assy l Procedure [1]
Switches and Volumes diagnosis of CUEVR Assy l Procedure [2]
1 Remove the Jumper wires which is unnecessary for CUEVR Assy diagnosis.
Disconnect the 3 FFCs of left side and 6 connectors of lower side from UCOM Assy.
(CN8401, 8402, 8404, 8405, 8407, 8408, 8409, 8411, 8415)
2 Remove the Barrier from UCOM Assy.
g Preparations
1 Disconnect the 4 FFCs of upper side from UCOM Assy.
(CN8406, 8410, 8412, 8420)
3 Lift up the UCOM Assy, and diagnose CUEVR Assy.
Remove the barrier as needed.
2 Remove the 4 screws.
(BBZ30P060FTC)
Procedure [1] LEDs diagnosis of CUEVR Assy
1
×4×4
2
3
×4×4
UCOM AssyUCOM Assy
UCOM Assy
UCOM Assy
CN8420CN8420
CN8406
CN8406
CN8410
CN8410
CN8412
CN8412
1
×9×9
UCOM AssyUCOM Assy
CN8415CN8415
CN8401
CN8401
CN8402
CN8402
CN8411CN8411CN8409CN8409CN8408CN8408CN8407CN8407CN8405CN8405CN8404CN8404
2
Barrier
Barrier
UCOM AssyCUEVR Assy
Diagnosis
To Next Page
