AlphaTheta DJM-V10 - 5.2 MATRIX INFORMATION

20
DJM-V10
1
2 3 4
A
B
C
D
E
F
1
2 3 4
5.2 MATRIX INFORMATION
g KEY MATRIX
Control UCOM : PNL1 UCOM
g DIRECT KEY
Control UCOM : PNL1 UCOM
g MULTIPLEXER AD
Control UCOM : PNL1 UCOM
g DIRECT AD
Control UCOM : PNL1 UCOM Control UCOM : PNL2 UCOM Control UCOM : PNL2 UCOM
SW/VR (KEY/AD)
KEY_GRID0 KEY_GRID1 KEY_GRID2 KEY_GRID3 KEY_GRID4 KEY_GRID5 KEY_GRID6 KEY_GRID7
KEY_SEG0
Function Name
BFX_CH1 CH1_CUE A LPF PRE EQ BFX_CH1 CH1_CUE B LPF MIC OFF
Assy Name
CUEVR CUEVR SFXB SFXB CUEVR CUEVR SFXB SFXB
KEY_SEG1
Function Name
BFX_CH2 CH2_CUE A HPA LINK CUE MONO SPLIT BFX_CH2 CH2_CUE B MASTER MIX TALK OVER
Assy Name
CUEVR CUEVR SFXB SFXB CUEVR CUEVR SFXB SFXB
KEY_SEG2
Function Name
BFX_CH3 CH3_CUE A BFX_MIC HPF BFX_CH3 CH3_CUE B BFX_MIC HPF
Assy Name
CUEVR CUEVR SFXB SFXB CUEVR CUEVR SFXB SFXB
KEY_SEG3
Function Name
BFX_CH4 CH4_CUE A SFX_S-DELAY SFX_D-ECHO BFX_CH4 CH4_CUE B SFX_S-DELAY SFX_D-ECHO
Assy Name
CUEVR CUEVR SFXB SFXB CUEVR CUEVR SFXB SFXB
KEY_SEG4
Function Name
BFX_CH5 CH5_CUE A SFX_L-DELAY SFX_REVERB BFX_CH5 CH5_CUE B SFX_L-DELAY SFX_REVERB
Assy Name
CUEVR CUEVR SFXB SFXB CUEVR CUEVR SFXB SFXB
KEY_SEG5
Function Name
BFX_CH6 CH6_CUE A SFX_EXT1 SFX_EXT2 BFX_CH6 CH6_CUE B SFX_EXT1 SFX_EXT2
Assy Name
CUEVR CUEVR SFXB SFXB CUEVR CUEVR SFXB SFXB
KEY_SEG6
Function Name
BFX_MASTER
MASTER_CUE A BEAT UP FREQ_LOW BFX_MASTER MASTER_CUE B BEAT UP BFX SEL1
Assy Name
CUEVR CUEVR BFXB BFXB CUEVR CUEVR BFXB BFXB
KEY_SEG7
Function Name
CH1 CRF A CH1 CRF B BEAT DOWN FREQ_MID CH4 CRF A CH4 CRF B BEAT DOWN BFX SEL2
Assy Name
CRFSW CRFSW BFXB BFXB CRFSW CRFSW BFXB BFXB
KEY_SEG8
Function Name
CH2 CRF A CH2 CRF B - FREQ_HI CH5 CRF A CH5 CRF B - BFX SEL3
Assy Name
CRFSW CRFSW - BFXB CRFSW CRFSW - BFXB
KEY_SEG9
Function Name
CH3 CRF A CH3 CRF B - HPB LINK CUE CH6 CRF A CH6 CRF B - BFX SEL4
Assy Name
CRFSW CRFSW - BFXB CRFSW CRFSW - BFXB
Function Name
MIDI ON/OFF MIDI START
(WAKEUP)
ISO ON/OFF MODE TYPE SND/RTN
ON_OFF
TAP EFECT ON/OFF
Assy Name PNLL PNLL PNLR PNLR PNLR
BFXB BFXB
TIME ENC_A TIME ENC_B
BFXB BFXB
VR Select
IC Port No
01234567
Multiplexer
SW
Signal
VR_SEL_C
00001111
VR_SEL_B
00110011
VR_SEL_A
01010101
Assy Name
MultiplexerAD
OUTPUT
Signal
AD_MUX0
CH3 SEND CH2 SEND CH1 SEND CH4 SEND BOOTH EQ H CH5 SEND BOOTH EQ L CH6 SEND
CUEVR
AD_MUX1
CH1 EQ M2 CH1 EQ L CH1 FILTER CH1 EQ M1 CH1 TRIM CH1 EQ H
CH1 INPUT SELECT CH1 COMP
PNLL
AD_MUX2
CH2 INPUT SELECT CH2 COMP CH2 EQ H CH2 TRIM CH2 EQ M2 CH2 FILTER CH2 EQ M1 CH2 EQ L
PNLL
AD_MUX3
CH3 TRIM
CH3 INPUT SELECT CH3 COMP CH3 FILTER CH3 EQ H CH3 EQ L CH3 EQ M1 CH3 EQ M2
PNLR
AD_MUX4
CH4 TRIM
CH4 INPUT SELECT CH4 COMP CH4 FILTER CH4 EQ H CH4 EQ L CH4 EQ M1 CH4 EQ M2
PNLR
AD_MUX5
CH5 INPUT SELECT CH5 COMP CH5 EQ H CH5 TRIM CH5 EQ M1 CH5 FILTER CH5 EQ M2 CH5 EQ L
PNLR
AD_MUX6
CH6 INPUT SELECT CH6 COMP CH6 EQ H CH6 TRIM CH6 EQ M1 CH6 FILTER CH6 EQ M2 CH6 EQ L
PNLR
AD_MUX7
- SND/RTN CH SEL ISO EQ M MASTER LEVEL ISO EQ H MASTER FILTER
SND FX RTN LEVEL
ISO EQ L PNLR
AD_MUX8
SEND FX TIME HP A LEVEL HP A MIX
MASTER MIX LEVEL TONE MIC EQ HI SIZE/FEEDBACK MIC EQ LOW
SFXB
Function Name Assy Name Function Name Assy Name Function Name Assy Name
RESONANCE
SFXB
CH1 FD
CHF1
CROSS FD3
CRFB
BOOTH LEVEL BFXB CH2 FD
CHF2
CROSS FD1
CRFB
HP B MIX BFXB CH3 FD
CHF3
CROSS FD2
CRFB
LEVEL/DEPTH BFXB CH4 FD
CHF4
CROSS FD0
CRFB
HP B LEVEL BFXB CH5 FD
CHF5
VR_SELECT -
TCP_YIN Touch panel CH6 FD
CHF6
TCP_XIN Touch panel
