Alpine CDE-136BT User Manual

15-EN
1 Press and hold AUDIOSETUP for at least 2 seconds to
activate the SETUP mode.
2 Turn the Rotary encoder to select AUDIO, and then press
ENTER.
BLUETOOTH  GENERAL  AUDIO  DISPLAY  iPod & USB
3 Turn the Rotary encoder to select the desired sound
setting menu, and then press ENTER.
FACTORY EQ
*1/*2
 3BAND EQ
*1/*3
 HPF
*1
 SUBWOOFER 
SUBW LPF
*4
 SUBW PHASE
*4
 SUBW SYS
*4
*1 Adjustment cannot be performed when DEFEAT is set to ON.
*2 Any changes made to either FACTORY EQ or 3BAND EQ are
reflected in the others’ settings.
*3 In step 3, three sound adjustment items (Bass, Mid and Treble)
can be selected in 3BAND EQ mode, turn the Rotary encoder
to select the desired item, and then press ENTER to continue
to step 4.
*4 These functions are inoperable when Subwoofer is set to OFF.
4 Turn the Rotary encoder to change the setting, and then
press ENTER.
(e.g. Select SUBWOOFER ON or SUBWOOFER OFF)
5 Press and hold AUDIOSETUP for at least 2 seconds to
return to normal mode.
Notes
• Pressing  returns to the previous Sound menu mode.
• If no operation is performed for 60 seconds, Sound menu mode is
canceled.
10 typical equalizer settings are preset at the factory for a variety of
musical source material. USER settings are created in the 3BAND EQ
mode.
USER  FLAT (Initial setting)  POPS  ROCK  NEWS  JAZZ
 ELEC DANCE  HIP HOP  EASY LIS  COUNTRY 
CLASSICAL
You can modify the Equalizer settings to create a response curve more
appealing to your personal taste. The setting of Bass, Mid and Treble can
be adjusted in this mode.
Setting the Bass Control
1 After selecting BASS from the 3BAND EQ adjustment
mode, turn the Rotary encoder to select the desired Bass
setting item, and then press ENTER.
WIDTH (Q)  CENTER FRQ  LEVEL
2 Turn the Rotary encoder to select the desired setting
value, and then press ENTER.
3 Press  to return to the previous step.
 Setting the Bass Bandwidth (WIDTH (Q))
Turn the Rotary encoder to select the desired bass
bandwidth.
WIDE 0.50  MEDIUM 1.00  MEDIUM 1.50 (Initial setting) 
NARROW 2.00
Changes the boosted bass bandwidth to wide or narrow. A wider setting
will boost a wide range of frequencies above and below the center
frequency. A narrower setting will boost only frequencies near the
center frequency.
 Setting the Bass Center Frequency (CENTER FRQ)
Turn the Rotary encoder to select the desired bass center
frequency.
60 (Hz)  80 (Hz)  100 (Hz) (Initial setting)  120 (Hz)
Emphasizes the displayed bass frequency ranges.
 Setting the Bass Level
Turn the Rotary encoder to select the desired bass level
(-7~+7)
*
.
You can emphasize or weaken the bass level.
* The adjustment can also be made by pressing AUDIO. Refer to
“Adjusting Subwoofer Level/Bass Level/Mid Level/Treble Level/
Balance (Between Left and Right)/Fader (Between Front and
Rear)/Loudness/Defeat” on page 14.
Setting the Mid Control
1 After selecting MID from the 3BAND EQ adjustment mode,
turn the Rotary encoder to select the desired Mediant
setting item, and then press ENTER.
WIDTH (Q)  CENTER FRQ  LEVEL
2 Turn the Rotary encoder to select the desired setting
value, and then press ENTER.
3 Press  to return to the previous step.
 Setting the Mid Bandwidth (WIDTH (Q))
Turn the Rotary encoder to select the desired Mid
bandwidth.
WIDE 0.75  MEDIUM 1.00  MEDIUM 1.25  NARROW 1.50
(Initial setting)
 Setting the Mid Center Frequency (CENTER FRQ)
Turn the Rotary encoder to select the desired Mid center
frequency.
500 (Hz)  1.0k (Hz) (Initial setting) 1.5k (Hz)  2.5k (Hz)
 Setting the Mid Level
Turn the Rotary encoder to select the desired Mid level (-7
~ +7)
*
.
You can emphasize or weaken the Mid level.
* The adjustment can also be made by pressing AUDIO. Refer to
“Adjusting Subwoofer Level/Bass Level/Mid Level/Treble Level/
Balance (Between Left and Right)/Fader (Between Front and
Rear)/Loudness/Defeat” on page 14.
Setting the Treble Control
1 After selecting TREBLE from the 3BAND EQ adjustment
mode, turn the Rotary encoder to select the desired
Treble setting item, and then press ENTER.
WIDTH (Q)  CENTER FRQ  LEVEL
2 Turn the Rotary encoder to select the desired setting
value, and then press ENTER.
Equalizer Presets (FACTORY EQ)
Adjusting the Parametric Equalizer Curve
(3BAND EQ)

Alpine CDE-136BT Specifications

General

Audio system	4.0
MP3 playback	Yes
DVD Audio playback	No
Playback disc formats	CD audio
Audio formats supported	AAC, CD-A, MP3, WMA
Video formats supported	Not supported
AM band range	531 - 1602 kHz
FM band range	87.5 - 108 MHz
LW band range	153 - 281 kHz
Supported radio bands	DAB+, FM, LW, MW
Preset stations quantity	48
Impedance	4 Ω
Output power	200 W
RDS features	AF, PTY, RT, TA, TP
Product color	Multicolor
Volume control	Digital
Frequency range	5 - 20000 Hz
Disc types supported	CD, CD-RW
Audio output channels	4.0 channels
Equalizer bands quantity	3
Signal-to-Noise Ratio (SNR)	105 dB
Display type	LCD
Display digits	14 digits
Display number of lines	1 lines
Display number of colors	Monochrome
USB version	2.0
Bluetooth version	3.0+HS
Bluetooth profiles	A2DP, AVRCP, HFP, HSP
USB ports quantity	1
Digital audio optical out	0
Apple docking compatibility	iPad, iPod
Cables included	USB
Material	Metal, Plastic
File format system	FAT 16/32
Power requirements	11 - 16 VDC
Compatible products	iPhone / iPod / Nokia
Remote control type	IR
Key illumination color	Multi
Number of optical discs	1 discs
Operating temperature (T-T)	-10 - 60 °C

Weight and Dimensions

Depth	161 mm
Width	178 mm
Height	50 mm
Weight	1500 g
