Alpine CDE-136BT User Manual

31-EN
iPod classic (80GB, 160GB): Ver.1.1.2
iPod nano (2nd generation): Ver.1.1.3
iPod with video: Ver.1.3
iPod nano (1st generation): Ver.1.3.1
• Confirmed devices regarding Made for iPhone. Correct function of
earlier versions cannot be guaranteed.
iPhone 4: Ver.4.2.1
iPhone 3GS: Ver.4.3
iPhone 3G: Ver.4.2.1
iPhone: Ver.3.1.3
• For clarity in identifying your model of iPod, please see Apple’s own
document “Identifying iPod models” at
http://support.apple.com/kb/HT1353
• This unit does not support video playback from iPod/iPhone, even
using a video-compatible cable.
Setting the iPod Control
When an iPod/iPhone is connected, operate it from its own controls or
from the head unit.
Press and hold ENTER for at least 2 seconds to switch
iPod control mode between HU (HEAD UNIT) and iPod.
Once the control mode is changed, this will set pause status,
press  to continue.
HU (HEAD UNIT):
Operate the iPod/iPhone via this unit.
iPod:
Operate the iPod/iPhone using its own controls. When iPod is
selected, some functions will not be operable via the head unit.
Note
• Depending upon the iPod used, iPod control may not be selectable. Or,
if iPod is selected, operation must still be from the head unit.
Playback
1 Press SOURCE to switch to the iPod mode.
2 Press  or  to select the desired song.
Pressing and holding  or  will fast backward/fast
forward the current track.
3 To pause playback, press .
Pressing  again will resume playback.
Notes
• A song playing on the iPod/iPhone while it is connected to this unit will
continue to play from where it was paused after disconnection.
• If you listen to an episode from a selected Podcast or Audiobook, the
episode can be changed by pressing  or .
• An episode may have several chapters. The chapter can be changed by
pressing  or .
Searching for a desired Song
An iPod/iPhone can contain hundreds of songs. By using file tag
information and keeping these songs organized in playlists, this unit’s
search functions will ease song searches.
Each music category has its own individual hierarchy. Use the Playlist/
Artist/Album/Song/Podcast/Genre/Composer/Audiobook search mode
to narrow searches based on the table below.
For example:
Searching by Artist name
The following example explains how an ARTIST search is performed.
Another search mode can be used for the same operation, although the
hierarchy differs.
1 Press ENTER to activate the search selection mode.
The “” indicator lights up.
2 Turn the Rotary encoder to select the ARTIST search
mode, and then press ENTER.
PLAYLIST  ARTIST  ALBUM  SONG  PODCAST  GENRE
 COMPOSER  AUDIOBOOK  PLAYLIST
3 Turn the Rotary encoder to select the desired Artist, and
then press ENTER.
4 Turn the Rotary encoder to select the desired Album, and
then press ENTER.
5 Turn the Rotary encoder to select the desired Song, and
then press ENTER.
Notes
• This function is unavailable when iPod is selected in “Setting the iPod
Control” (refer to “Setting the iPod Control” on page 31).
• After pressing and holding ENTER for at least 2 seconds while in
each hierarchy (except SONG and AUDIOBOOK hierarchy), all songs
of the selected hierarchy are played back.
• After selecting [ALL] in the search mode with “
*
”, press and hold
ENTER for at least 2 seconds to play back all songs in the iPod/
iPhone or selected search mode.
• While in the search mode, if you press and hold  for 2 seconds, or no
operation is performed for 60 seconds, the search mode is canceled.
• In the search mode, pressing  will return to the previous mode.
• When search is made during M.I.X. play, the M.I.X. play mode will be
canceled.
• “NO SONG” will be displayed if there are no songs in the selected
playlist in the PLAYLIST search mode.
• “NO PODCAST” will be displayed if there is no podcast data in the
iPod/iPhone in the PODCAST search mode.
• “NOAUDIOBOK” will be displayed if there is no audiobook data in the
iPod/iPhone in AUDIOBOOK search mode.
• If “iPod name” stored in the iPod/iPhone is selected in the desired
Playlist search mode, and ENTER is pressed, you can search for all
songs in the iPod/iPhone. Also, if you press and hold ENTER for at
least 2 seconds, all songs in the iPod/iPhone are played back.
Hierarchy 1 Hierarchy 2 Hierarchy 3 Hierarchy 4
Playlist Song — —
Artist
*
Album
*
Song —
Album
*
Song — —
Song———
Podcast Episode — —
Genre
*
Artist
*
Album
*
Song
Composer
*
Album
*
Song —
Audiobook — — —

Alpine CDE-136BT Specifications

General

Audio system	4.0
MP3 playback	Yes
DVD Audio playback	No
Playback disc formats	CD audio
Audio formats supported	AAC, CD-A, MP3, WMA
Video formats supported	Not supported
AM band range	531 - 1602 kHz
FM band range	87.5 - 108 MHz
LW band range	153 - 281 kHz
Supported radio bands	DAB+, FM, LW, MW
Preset stations quantity	48
Impedance	4 Ω
Output power	200 W
RDS features	AF, PTY, RT, TA, TP
Product color	Multicolor
Volume control	Digital
Frequency range	5 - 20000 Hz
Disc types supported	CD, CD-RW
Audio output channels	4.0 channels
Equalizer bands quantity	3
Signal-to-Noise Ratio (SNR)	105 dB
Display type	LCD
Display digits	14 digits
Display number of lines	1 lines
Display number of colors	Monochrome
USB version	2.0
Bluetooth version	3.0+HS
Bluetooth profiles	A2DP, AVRCP, HFP, HSP
USB ports quantity	1
Digital audio optical out	0
Apple docking compatibility	iPad, iPod
Cables included	USB
Material	Metal, Plastic
File format system	FAT 16/32
Power requirements	11 - 16 VDC
Compatible products	iPhone / iPod / Nokia
Remote control type	IR
Key illumination color	Multi
Number of optical discs	1 discs
Operating temperature (T-T)	-10 - 60 °C

Weight and Dimensions

Depth	161 mm
Width	178 mm
Height	50 mm
Weight	1500 g
