Alpine CDE-136BT User Manual

16-EN
3 Press  to return to the previous step.
 Setting the Treble Bandwidth (WIDTH (Q))
Turn the Rotary encoder to select the desired treble
bandwidth.
WIDE 0.75  NARROW 1.25 (Initial setting)
 Setting the Treble Center Frequency (CENTER FRQ)
Turn the Rotary encoder to select the desired treble
center frequency.
7.5K (Hz)  10.0K (Hz) (Initial setting)  12.5K (Hz)  15.0K (Hz)
 Setting the Treble Level
Turn the Rotary encoder to select the desired treble level
(-7~+7)
*
.
You can emphasize or weaken the treble level.
* The adjustment can also be made by pressing AUDIO. Refer to
“Adjusting Subwoofer Level/Bass Level/Mid Level/Treble Level/
Balance (Between Left and Right)/Fader (Between Front and
Rear)/Loudness/Defeat” on page 14.
The High Pass Filter on this unit can be adjusted to suit your personal
taste. This feature works best when used in conjunction with a
subwoofer.
 Setting item: HPF
Setting contents:
OFF (Initial setting) / 60 (Hz) / 80 (Hz) / 120 (Hz) / 160 (Hz)
All frequencies above the selected cutoff are output.
When the subwoofer is on, you can adjust the subwoofer output level
(refer to “Adjusting Subwoofer Level/Bass Level/Mid Level/Treble Level/
Balance (Between Left and Right)/Fader (Between Front and Rear)/
Loudness/Defeat” on page 14).
 Setting item: SUBWOOFER
Setting contents:
ON (Initial setting) / OFF
ON:
The subwoofer signal is output from the Subwoofer RCA
Connectors (refer to “Connections” on page 42).
OFF:
No subwoofer signal is output from the Subwoofer RCA
Connectors (refer to “Connections” on page 42).
The Low Pass Filter on this unit can be adjusted to suit your personal
taste.
 Setting item: SUBW LPF
Setting contents:
OFF (Initial setting) / LPF 60 (Hz) / LPF 80 (Hz) / LPF 120 (Hz) /
LPF 160 (Hz)
All frequencies lower than the selected cutoff are output.
The subwoofer output phase is toggled SUBWOOFER NORMAL (0°) or
SUBWOOFER REVERSE (180°). To adjust the level, turn the Rotary
encoder. Depending on the installation location of your subwoofer, one
of these settings may sound better than the other.
 Setting item: SUBW PHASE
Setting contents:
NORMAL (Initial setting) / REVERSE
When the subwoofer is on, you can select either SYS 1 or SYS 2 for the
desired subwoofer effect.
 Setting item: SUBW SYS
Setting contents:
SUBW SYS 1 / SUBW SYS 2 (Initial setting)
SUBW SYS 1:
Subwoofer level changes according to the main volume setting.
SUBW SYS 2:
Subwoofer level change is different from the main volume setting.
For example, even at low volume settings, the subwoofer is still
audible.
Adjusting the High Pass Filter
Turning Subwoofer ON/OFF
Adjusting the Low Pass Filter
Setting the Subwoofer Phase
Setting the Subwoofer System

Alpine CDE-136BT Specifications

General

Audio system	4.0
MP3 playback	Yes
DVD Audio playback	No
Playback disc formats	CD audio
Audio formats supported	AAC, CD-A, MP3, WMA
Video formats supported	Not supported
AM band range	531 - 1602 kHz
FM band range	87.5 - 108 MHz
LW band range	153 - 281 kHz
Supported radio bands	DAB+, FM, LW, MW
Preset stations quantity	48
Impedance	4 Ω
Output power	200 W
RDS features	AF, PTY, RT, TA, TP
Product color	Multicolor
Volume control	Digital
Frequency range	5 - 20000 Hz
Disc types supported	CD, CD-RW
Audio output channels	4.0 channels
Equalizer bands quantity	3
Signal-to-Noise Ratio (SNR)	105 dB
Display type	LCD
Display digits	14 digits
Display number of lines	1 lines
Display number of colors	Monochrome
USB version	2.0
Bluetooth version	3.0+HS
Bluetooth profiles	A2DP, AVRCP, HFP, HSP
USB ports quantity	1
Digital audio optical out	0
Apple docking compatibility	iPad, iPod
Cables included	USB
Material	Metal, Plastic
File format system	FAT 16/32
Power requirements	11 - 16 VDC
Compatible products	iPhone / iPod / Nokia
Remote control type	IR
Key illumination color	Multi
Number of optical discs	1 discs
Operating temperature (T-T)	-10 - 60 °C

Weight and Dimensions

Depth	161 mm
Width	178 mm
Height	50 mm
Weight	1500 g
