Specifications
FM TUNER SECTION
AM TUNER SECTION
CD PLAYER SECTION
USB SECTION
* Frequency response may differ depending on the encoder software/bit
rate.
PICKUP
BLUETOOTH SECTION
GENERAL
* Primary amplifier ratings per CEA-2006 Standard
Power output: measured at 4 Ohms and ≤ 1% THD+N
S/N: 80 dBA (reference: 1 W into 4 Ohms)
CHASSIS SIZE
NOSEPIECE SIZE
Note
Due to continuous product improvement, specifications and design are
subject to change without notice.
Tuning Range 87.7~107.9 MHz
Mono Usable Sensitivity 9.3 dBf (0.8 μV/75 ohms)
50 dB Quieting Sensitivity 13.5 dBf (1.3 μV/75 ohms)
Alternate Channel Selectivity 80 dB
Signal-to-Noise Ratio 65 dB
Stereo Separation 35 dB
Capture Ratio 2.0 dB
Tuning Range 530-1,710 kHz
Sensitivity (IEC Standard) 22.5 μV/27 dB
Frequency Response 5~20,000 Hz (±1 dB)
Wow & Flutter (% WRMS) Below measurable limits
Total Harmonic Distortion 0.008% (at 1 kHz)
Dynamic Range 95 dB (at 1 kHz)
Signal-to-Noise Ratio 105 dB
Channel Separation 85 dB (at 1 kHz)
USB requirements USB 1.1/2.0
Max. Power Consumption 500 mA
USB Class Mass Storage
File System FAT 12/16/32
MP3 Decoding MPEG AUDIO Layer-3
Number of Channels 2-Channel (Stereo)
Frequency Response
*
5~20,000 Hz (±1 dB)
Total Harmonic Distortion 0.008% (at 1 kHz)
Dynamic Range 95 dB (at 1 kHz)
Signal-to-Noise Ratio 105 dB
Channel Separation 85 dB (at 1 kHz)
Wave length 795 nm
Laser power CLASS I
BLUETOOTH Specification BLUETOOTH V 3.0
Output Power +4 dBm Max. (Power class 2)
Profile HFP (Hands-Free Profile)
HSP (Head Set Profile)
A2DP (Advanced Audio
Distribution Profile)
AVRCP (Audio/Video Remote
Control Profile)
Power Requirement 14.4 V DC
(11~16 V allowable)
Power Output 18 W RMS × 4
*
Maximum Pre-Output Voltage 2 V/10 k ohms
Bass ±14 dB at 100 Hz
Mid ±14 dB at 1 kHz
Treble ±14 dB at 10 kHz
Loudness 10 dB at 100 Hz
Weight 1.6 kg (3 lbs. 8 oz)
Width 178 mm (7")
Height 50 mm (2")
Depth 161 mm (6~3/8")
Width 170 mm (6~3/4")
Height 46 mm (1~13/16")
Depth 25 mm (1")
