Alpine ICS-X8 User Manual

71-EN
01GB06ICS-X8.fm
ALPINE ICS-X8 68-13530Z91-A (EN)
Nokia Drive and Nokia Music applications are made available by
connecting compatible Nokia phones to the ICS-X8. The Nokia phone
require a specific software to support this feature. To obtain more details
about the underlying technology and the compatible phones, please visit
www.alpine-europe.com , www.nokia.com.
DISCLAIMER
ENABLED BY CONNECTIVITY FUNCTIONS OF THE NOKIA
PHONE, THE MOBILE PHONE'S USER INTERFACES FOR MUSIC
OR DRIVE ARE DISPLAYED DIRECTLY ON OUR HEAD UNIT
WITH NO ALTERATION.ALPINE SHALL NOT BE RESPONSIBLE
OR LIABLE TO USERS FOR ANY DAMAGES,LOSSES OR COSTS
RELATED TO OR ARISING OUT OF THESE MOBILE PHONE
INTERFACES.
Using a Nokia Application
To use a Nokia application, connect a compatible Nokia phone to the
USB connector with the attached cable.
1 Press the Home button.
The Home screen is displayed.
2 Touch [Nokia Drive] or [Nokia Music].
The screen for the selected application is displayed.
• Nokia applications can only be linked to when connected to a Nokia
phone that is compatible with this unit. Check the Alpine website for
compatible models.
• After connecting to a Nokia phone that is compatible with this unit,
application icons will appear on the Home screen.
• If you have displayed a screen other than Nokia Drive or Nokia
Music using the Nokia phone, ICS-X8 will display the Home screen.
• The Nokia phone applications that can be controlled are “Nokia
Drive” and “Nokia Music.”
• If the Nokia phone is locked, it cannot be operated from the unit.
• If the built-in GPS of the Nokia phone does not function due to usage
conditions, the GPS antenna (optional) connected to this device can
be used.
• The Nokia phone connection capacity is 1 phone only. If a second
phone is connected, a message saying, “USB device error,” will be
displayed.
1 Press the Home button.
The Home screen is displayed.
2 Touch [Nokia Drive].
The display shows the Nokia Drive screen.
In Nokia Drive, you can use the direct touch function. You
can operate the map by directly touching the operation
buttons displayed on the screen.
Some Nokia Music can be operated from this device.
1 Press the Home button.
The Home screen is displayed.
2 Touch [Nokia Music].
The display shows the Nokia Music screen.
• Operations can be performed by touching the onscreen buttons
or pressing the Media Control button.
• Depending on the connected model, some functions cannot be
operated.
Nokia(Optional)
When using a Nokia application, we recommend that
you connect the Nokia phone via both USB and
BLUETOOTH.
• For details on BLUETOOTH connection, refer to “Registering the
BLUETOOTH Device” (page 41).
Displaying the Nokia Drive
Play Nokia Music
01GB00ICS-X8.book Page 71 Wednesday, November 9, 2011 7:39 PM

Alpine ICS-X8 Specifications

General

MP3 playback	Yes
Playback disc formats	CD audio
Audio formats supported	AAC, MP3, WMA
Video formats supported	AVI, DIVX
AM band range	531 - 1602 kHz
FM band range	87.5 - 108 MHz
LW band range	153 - 281 kHz
Supported radio bands	AM, LW, MW
Preset stations quantity	30
Output power	200 W
RDS features	AF, EON, PTY, TA, TP
Product color	Black
Frequency range	5 - 20000 Hz
Disc types supported	CD, CD-R, CD-RW, DVD, DVD+R, DVD+RW, DVD-R, DVD-RW
Audio output channels	2.0 channels
Equalizer bands quantity	9
Analog signal format system	NTSC, PAL
Signal-to-Noise Ratio (SNR)	100 dB
Display type	LCD
Display diagonal	7 \
Display resolution	800 x 480 pixels
On Screen Display (OSD) languages	DEU, DUT, ENG, ESP, FIN, FRE, ITA, NOR, POR, RUS, SWE
USB version	2.0
Bluetooth version	2.1+EDR
Bluetooth profiles	A2DP, AVRCP, HFP, OPP, PBAP, SPP
USB ports quantity	2
Apple docking compatibility	Not supported
Cables included	USB
File format system	FAT 16/32
Power requirements	14.4V DC
Compatible products	iPod touch 4G/3G/2G/1G\\r iPod nano 6G/5G/4G/3G/2G/1G\\r iPod classic\\r iPod video\\r iPhone 4\\r iPhone 3GS\\r iPhone 3G\\r iPhone\\r Nokia 700, 701, 603, 808\\r Nokia N9, N8, E6, E7, X7, C6-01, C7
Operating temperature (T-T)	-20 - 60 °C

Weight and Dimensions

Weight	2600 g
Dimensions (WxDxH)	178 x 159 x 100 mm
