16
10
Channel gain
Push the fader left and right to adjust the channel gain, that it, to adjust the volume of
the output channel; the adjustable range is: -60dB ~ +6dB.
11
Debugging
Select “Copy channel EQ / volume from left to right” or “Copy channel EQ / volume
from right to left”.
12
Reset channel type
You can set the current channel type as Factory setting.
13
Mute control
Select mute or unmute all channels with just one key.
14
Reset EQ
Reset EQ setting.
15
Restore EQ, Direct EQ
Switch the tuned EQ data to direct state, click it again to restore the EQ data before
Direct EQ setting.
16
Output channel
There are 8 output channels to choose from. Configure the type of output channel.
Click the speaker button to mute.
Description of PC software - EQ
