Alpine PXE-R80-8 - Functional Parameters

20
Input signals
6 channels of high-voltage-level, 2 channels of RCA audio and high resolution
Bluetooth
Output signals
8 channels of high voltage level, and 8 channels of RCA audio
Signal gain of output channel
Range: mute, -60.0dB ~ +6.0dB
Output signal equalizer
Type: parametric EQ, graphic EQ
Frequency: 20Hz ~ 20kHz; resolution: 1Hz
Q value (slope or gradient): 0.404 ~ 28.852
Gain: -12.0dB ~ +12.0dB; resolution: 0.1dB ~ 0.5dB ~ 1.0dB
Output signal frequency divider
Each output channel is equipped with independent multi-order high-pass filter,
Filter type: Linkwitz-Riley, Bessel or Butterworth
Filter cross-over frequency: 20Hz ~ 20kHz; resolution: 1Hz
Filter slope (gradient): -6dB/Oct ~ -48dB/Oct
Output phase
Normal phase or reverse phase (0° ~ 360°)
Output delay
0.000 ~ 8.000ms, 0 ~ 277cm, 0 ~ 109inch
Pre-set sound effects
Multiple sets of pre-set sound effects data can be saved in the device, call of
online sound effects is supported
Functional parameters
