Alpitronic hypercharge HYC 50 User Manual

HYC_50 – Operation and Installation Guide
Hardware
Version 1-2
Page 16 of 76
2 Product description
All rights reserved. Reproduction of this document, in whole or in part, is only permitted with the permission of alpitronic GmbH.
2.1. Charging interfaces
The following charging interfaces can be selected for the HYC_50 in various combinations.
Active cooling is not provided for any of the cable variants.
Charging Interface
Charging interface
Voltage [V]
Current [A]
Min.
Max.
Min.
Max.
CCS1/2
150 V DC
1.000 V DC
6,5 A
150 A DC
CHAdeMO
150 V DC
500 V DC
6,5 A
125 A DC
GB/T
150 V DC
750 V DC
6,5 A
150 A DC
Table 2: Charging interfaces
Attention
The total power of the HYC_50 is limited to a nominal current of 90 A.
Information
The CCS1 (US) and GB/T (China) options are special options for the
automotive industry.
The following combinations are possible:
Charging interfaces
Outlet 1 (right)
Outlet (left)
CCS1/2
N/A
CCS1/2
CHAdeMO
CCS1/2
CCS1/2
CCS1/2
GB/T
N/A
GB/T
N/A
CCS1/2
N/A
CHAdeMO
Table 3: Possible combinations of charging interfaces
