Alpitronic hypercharge HYC 50 User Manual

HYC_50 – Operation and Installation Guide
Hardware
Version 1-2
Page 24 of 76
2 Product description
All rights reserved. Reproduction of this document, in whole or in part, is only permitted with the permission of alpitronic GmbH.
Identifier
Description
-BE1
DC meter charging point left
-BE2
DC meter charging point right
-EP1
Fan interior
-EP2
Blower
-FC1
Input fuses HYC_50 (135 A)
-FC2
HV-PSU fuse (4 A)
-FC3
Output fuse charging point left
-FC4
Output fuse charging point right
-KF1
GRID – Mains connection/fuse protection
-KF2
CTRL_CHRG – charging controller
-KF3
POWER_UNIT – AC/DC converter
-KF4
DC-output switchgear
-KF5
DC Block left
-KF6
DC Block right
-KF7
CON_FRONT – control front
-PF1
LED-strip left
-PF2
LED-strip right
-PH1
Touch display
-PH2
Card reader terminal (optional position)
-PH3
Terminal (RFID), antenna
-PH4
CTRL_DISPEXT_50 – Calibration law display charging point left
-PH5
CTRL_DISPEXT_50 – Calibration law display charging point right
-QB1
main switch / 3P
-QB2
DC-relay charging point left
-QB3
DC-relay parallel switching relay power modules
-QB4
DC-relay charging circuit right
-SF1
Door contact
-TB1
HV_PSU – 24V/48V auxiliary power supply
-TB2
PFC – coil
-TB3
Transformer
-XD1
Connection terminals Mains input
-XD2
DC busbar for vehicle line connection XD4 (DC output left)
-XD3
DC busbar for vehicle line connection XD5 (DC output right)
-XD4
DC charging connection left (depending on configuration)
-XD5
DC charging connection right (depending on configuration)
-XD6
DC link connector
-XF1
Ethernet network connector (service)
-XF2
Ethernet network connector (client-LAN)
Table 4: Components of the HYC_50
