2. Product description
The HYC_50 from the hypercharger product family can be equipped with the following
options:
Table 1: Overview DC Power and Options HYC_50
Classification according to DIN EN 61851-23
Depending on the configuration, the DC charging station supports up to two outputs for
simultaneous operation while maintaining galvanic isolation between the mains and the
vehicles and between the vehicles themselves. The design corresponds to circuit diagram
3 according to table GG.2 of the standard E DIN EN 61851-23:2018-03 (VDE 0122-2-
3:2018-03).
The charging station does not support an optional ventilation function.
Figure 1 and Figure 2 show the HYC_50 which can be equipped with one or two DC charging
cables.
Figure 1: HYC_50 with open front door (Example with two DC charging cables)
