HYC_50 – Operation and Installation Guide
Hardware
Version 1-2
4 HYC_50 Installation and commissioning
All rights reserved. Reproduction of this document, in whole or in part, is only permitted with the permission of alpitronic GmbH.
4.2.2. Connecting the mains cables
The HYC_50 charging stations can be used in TT and TN-S, TN-C and TN-C-S type supply
networks.
Attention
The necessary protective measures against electric shock and other
country-specific requirements must be taken into account and
implemented before commissioning the charging pole.
This product is designed for type A environments (interfering emissions),
the immunity is equivalent to type A environments.
Depending on the mains voltage and the configuration of the HYC_50, a
protective earth current of up to 300 mA may flow. This must be taken
into account when designing the protective earthing and protective
measures.
This product can cause a DC current > 6 mA in the protective conductor.
Where a residual current-operated protective device (RCD) is used for
protection against electrical shock, only an RCD of Type B or B+ is
allowed on the supply side of this product.
An I
N
= 300 mA is recommended.
Any optionally connectable external signals may only be designed and
connected as SELV signals.
After the HYC_50 has been mechanically installed (see Chapter 4.1), the mains cables can
be screwed to the isolator at the input.
Recommended conductor cross-sections:
Table 7: Recommended cross-sections
Attention
The outer diameter of the connection cable must be in the range of
24 mm and 35 mm to ensure tightness at the cable entry seal.
Diameters larger than 35 mm cannot be mechanically
accommodated.
