2.5. Opening the HYC_50
The HYC_50 has a front door that can be opened via a locking lid on the left side (below the
charging plug holder). This has two locking cylinders (10/30 mm profile half cylinder).
The locking cylinder on the left (see Figure 6) is the one for alpitronic support, the customer
locking cylinder is on the left (empty on delivery).
Steps to open the inlet:
• turn the key 90° in the direction shown in Figure 6
• tilt the inlet forward and down.
Steps to close the inlet:
• insert the nose of the inlet into the opening at the bottom and
• push the inlet up into the center of the opening until it snaps into place
Figure 6: Locking lid of the HYC_50
After opening the locking lid, the front door lock can be released and the door opened.
Figure 7: Front door locking mechanism
