Alpitronic hypercharge HYC 50 User Manual

HYC_50 – Operation and Installation Guide
Hardware
Version 1-2
11 Technical data
Page 75 of 76
All rights reserved. Reproduction of this document, in whole or in part, is only permitted with the permission of alpitronic GmbH.
11. Technical data
General technical data and operating conditions:
Parameter
Nominal value
Protection class
IP55
Mounting location
Indoor and Outdoor
Humidity range for operation or storage
0…95 % rel. (non-misting)
Humidity range for operation
0…95 % rel.
Pollution degree
4
Storage temperature range
-40 °C … +55 °C
Operating temperature range
-30 °C … +40 °C (+55 °C with derating)
Mechanical impact resistance (IEC62262)
IK10
Mounting type
Wallmount or Stand
Accessibility
Without restrictions
Installation height
up to a maximum of 4,000 m.a.s.l.
Protection class
Class I (protective grounding)
Supported charging modes
Mode 4
Max. Air flow rate HYC_50
420 m
3
/h
Mechanical environmental conditions
M1
Electromechanical environmental conditions
E2
Accuracy class
A
Table 13: Technical data
Type
Width [mm]
Hight [mm]
Depth [mm]
Weight [kg]
HYC_50
520
1300
220
95 … 145 kg
Table 14: Mechanical Data
Electrical connection data HYC_50
Parameter
Nominal value
Operating voltage U
r
3x 380…400 Vac +PE (-15%...+10%)
Frequency
50 Hz (±5%)
Rated current I
r
90 A
Efficiency
95 % @P
r
(worst case)
Backup-fuse / circuit breaker to be used
(mandatory)
fuse 125 A gG (gL)
circuit breaker 125 A (Type B or C)
Max. connection cross-section
50 mm²
Permissible outer diameter of the supply line
24…35 mm
Max. Rated short-circuit current I
pk
17 kA (peak)
Conditional rated short-circuit withstand current
I
cw
1,4 kA (rms) @1s
Contribution to the short-circuit current
I
r
Overvoltage category
OVC III
Integrated surge protection (SPD)
Type 1+2+3
Table 15: Electrical connection data HYC_50
