Alpitronic hypercharge HYC 50 User Manual

HYC_50 – Operation and Installation Guide
Hardware
Version 1-2
Page 44 of 76
4 HYC_50 Installation and commissioning
All rights reserved. Reproduction of this document, in whole or in part, is only permitted with the permission of alpitronic GmbH.
of traces of condensation?
Check the air and creepage distances
☐
☐ OK ☐ deficient
Check the filter mats
☐
☐ OK ☐ deficient
Mains voltage correct?
☐
☐ OK ☐ deficient
Functional check of the electrical protective
devices
☐
☐ OK ☐ deficient
Earthing system complete? Equipotential
bonding connections complete?
☐
☐ OK ☐ deficient
Possible remarks:
Checks at first switch-on:
Check
Executed
Result
Checking fan noise
☐
☐ OK ☐ deficient
Functional check of the RFID reader
☐
☐ OK ☐ deficient
Functional check of the screen touch function
☐
☐ OK ☐ deficient
Functional check of the screen
☐
☐ OK ☐ deficient
Functional check of the LED strips in the front
☐
☐ OK ☐ deficient
Possible remarks:
Charging tests must be carried out for each individual charging point:
Charging
test
Peak-Power
Charged
energy
Executed
Result
Charging
point 1
☐
☐ OK ☐ deficient
Charging
point 2 (if
available)
☐
☐ OK ☐ deficient
Possible remarks:
The following photos are to be enclosed:
☐ Front and closing hatch each closed and open
☐ Type plate (badge outside on the lower edge of the HYC_50)
☐ CTRL_CHRG with identifiable connections
☐ Type plate (badge outside at the bottom edge of the hypercharger)
☐ Cable connection area with recognizable connections
☐ Location photo
