56 EAV64301 01/2015
B Side by side
IP20
Frame sizes 1, 2 and 3: possible
Frame sizes 4 and 5: possible, 2 drives only
Frame size 6: only at ambient temperature lower than 40 °C (104 °F)
C Individual IP20
Frame sizes 1, 2 and 3: no restriction of clearance
Frame sizes 4, 5 and 6: a 110 mm (4.33 in.)
Mounting Figure
No Type / IP
