COMPONENTS
Vector™ H Serie s ▪ S ervice M an ual ▪ MN-4 6 543 ▪ R ev 01 ▪ 11/ 1 9
32
Terminal Blocks (VFDs and Cooling Fans)
Ref. Description
1 TB 4 - L2
2 TB 5 - L1
3 TB 6 - L2
(switched)
4 Ground
VMC-PHD-001939
1
2
3
4
