DMZ Port Filtering Configuration
Feature Description
Enabled Name Name of the network service being forwarded, optional field
Source IP Start The beginning IP address that is allowed to send packets to the
DMZ
Source IP End The ending IP address that is allowed to send packets to the
DMZ
Protocol Select the protocol type, UDP or TCP
DMZ Port Start The beginning port range that will be allowed to send packets to
the DMZ
DMZ Port End The ending port range that will be allowed to send packets to the
DMZ
Virtual Server Configuration
Virtual server is also called port forwarding, and is where the WiFlyer forwards all traffic
received on an external port to a computer on the internal network. A virtual server is
required when internal computers need to run network servers, such as a web-server.
The WiFlyer can be configured as a virtual server so that remote users accessing Web or
FTP services via the public IP Address can be automatically redirected to local servers in
the LAN (Local Area Network). The WiFlyer firewall feature filters out unrecognized
packets to protect your LAN network so all computers networked with the WiFlyer are
invisible to the outside world. If you wish, you can make some of the LAN computers
accessible from the Internet by enabling Virtual Server. Depending on the requested
service, the WiFlyer redirects the external service request to the appropriate server within
the LAN network.
Note: Using the same port number for a virtual server that is being used by the WiFlyer
for the web-server or upgrade service will prevent the WiFlyer services from working.
The default ports for the webserver and upgrade service are TCP port 80 and UDP port
69.
Feature Description
Enabled Name Enter the name referencing the virtual service.
IP Address The server computer in the LAN (Local Area Network)
that will be providing the virtual services.
Private Port The port number of the service used by the Private IP
computer.
Protocol The protocol used for the virtual service.
Public Port The port number on the WAN (Wide Area Network) side
that will be used to access the virtual service.
19
