Ambient Weather WS-5000 User Manual

Version 1.10 ©Copyright 2020, Ambient LLC. All Rights Reserved. Page 53
17
Event Rain (in)
18
Daily Rain (in)
19
Weekly Rain (in)
20
Monthly Rain (in)
21
Yearly Rain (in)
Figure 44
6.10.2 Exporting Channel 1-8 Data
The SD Card must be inserted into the console and remain inserted to record channel 1-8 sensor data. Whenever there is
a new data set recorded, it will be added to this file.
The sensor data is not saved to on-board flash due to memory constraints; it is only saved to the SD card.
YYYYCH1A.csv is the channel sensor data and is only generated when the SD Card is inserted into the tablet.
6.10.3 About
Provides detailed information for troubleshooting purposes.
Figure 61
7. Glossary of Terms
Term
Definition
Absolute Barometric
Pressure
Absolute pressure is the measured atmospheric pressure and is a function of altitude, and to a
lesser extent, changes in weather conditions.
Absolute pressure is not corrected to sea-level conditions. Refer to Relative Barometric
Pressure.
Accuracy
Accuracy is defined as the ability of a measurement to match the actual value of the quantity
being measured.
Barometer
A barometer is an instrument used to measure atmospheric pressure.
Calibration
Calibration is a comparison between measurements – one of known magnitude or correctness
of one device (standard) and another measurement made in as similar a way as possible with a
second device (instrument).

Ambient Weather WS-5000 Specifications

General

Wireless Frequency	915 MHz
Wind Speed Accuracy	± 1 mph
UV Index Range	0 to 16
Light Range	0 to 200, 000 Lux
Solar Radiation Range	0 to 1800 W/m²
Connectivity	Wi-Fi
Display Type	TFT LCD
Transmission Distance	1000 feet
Temperature Range	-40 to 140 °F
Humidity Range	10% to 99%
Wind Direction	0° to 360°
Rainfall Measurement	0 to 999.9 inches
Power Source (Outdoor Sensor)	Solar panel with battery backup
Console Power Source	5V DC adapter
Data Storage	Ambient Weather Network
Compatibility	Amazon Alexa, Google Assistant, IFTTT
