U10C034 Telephony Version v1.4 June 2008
86
pktcNcsEndPntConfigCallAgentUdpPort
Contains the call agent User Datagram Protocol (UDP) receive port that is being used for this
instance of call signaling, i.e. the default port on which the call agent receives NCS signaling from
the gateway. The default port number is
2727.
pktcNcsEndPntConfigStatus
Contains the Row Status associated with the pktsNcsEndPntTable.
pktcNcsEndPntConfigCallWaitingMaxRep
Contains the maximum number of repetitions of the call waiting tone that the MTA plays from a
single CMS request. A value of zero
(0) can be used if the CMS is to control the repetitions of the
call waiting tone.
pktcNcsEndPntConfigCallWaitingDelay
Contains the delay between repetitions of the call waiting tone that the MTA plays from a single
CMS request.
pktcNcsEndPntStatusCallIpAddress
Contains the IP address of the CMS currently being used for this endpoint. This IP address creates
the appropriate security association.
pktcNcsEndPntStatusError
Contains the error status for this interface. The operational state indicates that all operations
necessary to put the line in service have occurred.
The
noSecurityAssociation status indicates that no security association yet exists for this endpoint.
The disconnected status indicates one of the following:
1. If
pktcMtaDevCmsIpsecCtrl is disabled, then no security association is involved with this
endpoint; the NCS signaling firmware is in the process of establishing the NCS signaling link
through an RSIP exchange.
2. Otherwise,
pktcMtaDevCmsIpsecCtrl is enabled, the security association has been established
and the NCS signaling firmware is in the process of establishing the NCS signaling link through an
RSIP exchange.
6.3 LED Verification
Installer can check the LED pattern table to know which state modem kept. If modem has registered
CMTS, PWR, DS, US and Online must be lit. If Tel1 is always flash and Tel2 is always unlit, it
means that MTA can not receive a valid offer from DHCP server. If Tel1 is always unlit and Tel2 is
always flash, it means that MTA can not download configuration file. If Tel1 and Tel2 are flash, it
means that the MTA does not send RSIP to CMS yet (waiting for MWD timeout).
