- 59 -
C141501700.fm
User's manual
GB
2-Unscrew the nuts (E) and un-
thread the brackets (F).
3-Remove the battery (G) and fit
the replacement.
4-Perform the same operations
to replace the other battery
(G) (if present).
Important
Do not dump used batteries.
Spent batteries must be dis-
posed of in accordance with cur-
rent statutory regulations.
5-Assemble the brackets (F)
complete with batteries.
6-Tighten the nuts (E).
IDM - 41501702400.tif
nut (E)
bracket (F)
bracket (F)
IDM - 41501703400.tif
battery (G)
battery (G)
IDM - 41501702400.tif
nut (E)
bracket (F)
bracket (F)
