Ambul T5 User Manual

H-1.601. 00137-B3.0
Page 29 of 81
4 Installation
4.1 Overview
Generally, T5 needs to be mounted only fixed onto an ambulance, helicopter
or aircraft. In such case, we will supply a specific mounting bracket as an
accessory.
If T5 is supplied by being fixed completely onto a stretcher or packed in a
first-aid package as an assembly, this equipment is well ready for use without
mounting.
Warning：
After mounting, you must perform a functional inspection (refer to Section 7
- Functional Inspection) to ensure proper operation of the equipment.
4.2 Boxed object
T5 Emergency Ventilator is packaged in a single case. For details on packing
list, refer to "10. T5 Supplies Configuration".
4.3 Install the battery
T5 is equipped with chargeable lithium battery which is installed as shown in
the following figure.
FIGURE 16 Install the battery

Ambul T5 Specifications

General

Brand	Ambul
Model	T5
Category	Medical Equipment
Language	English
