H-1.601. 00137-B3.0
Page 69 of 81
Caution：
1. The ventilator may fail when operating not under the conditions as
specified by the manufacturer. Make sure that the ventilator operates
under the conditions as specified by the manufacturer to ensure stable
service.
2. The ventilator may be subject to performance degradation when
operating not under the conditions as specified by the manufacturer.
Excessive operating pressure may damage interior sensor. Make sure that
the ventilator operates within the operating pressure range as specified
by the manufacturer to ensure stable service.
11.8
T5 Product Structure Diagram
FIGURE 43 T5 Product Structure Diagram
11.9
Available Minimum Oxygen Concentration
The oxygen concentration as indicated here is a calculated value, not based
on oxygen concentration FiO2 measured with oxygen concentration sensor,
but based on the flow rate of inhaled air and output air sum as measured.
