37
www.amcelettronica.com
KX series v.1.70
PROXIMITY SMALL
not certified EN 50131
Bring the tag near the key reading area (see fig.) on the reader. The arming signalling LEDs
will activate to indicate the chosen program. Move the key away when the chosen arming
type is displayed.
How it is used:
IMPORTANT: individual LEDS for each type of reader can be freely associate with each partial. Therefore, you can
have readers with LEDs that activate different programs depending on their position in the site to be protected
Programmable signalling LEDs
Move the tag close to the internal frame on the reader. The courtesy lights and arming signalling LEDs will light up at the same time
to indicate the chosen program. Move the key away when the chosen arming type is displayed. (total, partial 1, etc.)
NOTE: all tampers must be closed for the device to operate properly
How it is used:
Courtesy LEDs notify of key reading and
remain lit to indicate that the reader is
processing the operation. You can move
the key close to it again once the lights
go out.
KEY
Reading
area
