4
www.amcelettronica.com
KX series v.1.70
INTRODUCTION
X an K series are security control panel for building protection with certifification*
EN 50131-1 + EN 50131-3 + EN 50131-6 (control and indicating equiment for alarm system) +
EN 50136-1 + EN 50136-2 2013 (LAN - GPRS - GSM and PSTN alarm transmission)
Certifier IMQ – Sistemi di sicurezza.
The control panel are equipped of 4/8 zones, expandable to 16/32/64 with remote modules.
It is possible to obtain more zones by doubble and triple EOL split line, this configuration is not certified to EN 50131
ALARM COMUNICATION
X K series are able to notify one or more situations of ALARM, ROBBERY, TAMPERING AN TROUBLE with different carriers:
- PSTN LINE ON BOARD type ATS3/SP3 refered to EN 50136-2:2013 **
- GSM/GPRS optional module type ATS3/SP3 refered to EN 50136-2:2013 **
- IP module optional type ATS3/SP3 refered to EN 50136-2:2013 **
The programmming can be via local keypad or a PC with specific software.
* after specific programming and by enable the automatic EN configurator in panel (see description below)
** to ensure the classification SP3 the periodic test call must be programmed for work every 30’ minutes, or for
have classification SP2, the periodic test call can be programmed for work every 25h.
See the table with option below
NOTIFICATION EQUIPMENT DESCRIPTION AND CONFIGUARATION
Option A program 2 outs internal siren + SP2 comunication device (PSTN or GSM/GPRS or LAN)
Option B Autopowered Siren + SP2 comunication device (PSTN or GSM/GPRS or LAN)
Option D SP3 comunication device (PSTN or GSM/GPRS or LAN) with life test call every 30’
The notifications of alarm, robbery, intrusion, fault, manipultion, and other conditions must be signaled by ATS and Siren, in accor-
dance with the requirements specified in Tables to ensure the certification EN 50131-1:2013 and the grade certified.
LEVELS OF ACCESS
The standard EN 50131 defines the following access levels:
Level 1: access by any person (no code require)
Level 2: User Access by code. Level 2 is the access of person that will use the system like ARM/DISARM and all operation that the
rules of EN 50131 approval permitted. This level allows the entry of the code level 3 (installer)
Level 3: Intsaller. This level is the person or gorup of persons that will program all function of panel according with rules of EN
approval and in according with specific needs of Final user LEVEL 2. Another important function of Level 3 is teach to the user level
2 how to use the system when is already programmed.
Level 4: this is the manufactorer level, this access allow to modify the internal function of system. This level has the obligation to
build and design the system following the current standards.
EVENT STORAGE SYSTEM
The system has a memory for storage all events produced from panel, the number of these events is 1000, when the system will
arrive at the end of the number of events storable, will proceed to delete the old one of the1000 registered.
All events are stored in EEPROM components, and therefore not erasable and remain always stored, also in case
of absence of main power.
The delete of events can be made only by the manufacturer.
DEVICES FOR CONTROL OF THE SYSTEM
There are 2 type of device for control of panel:
Type A: Klcd and Klight
Type B: Klight plus
see the explanation in this manual
