65
www.amcelettronica.com
KX series v.1.70
When is selected the timer, set the hour and selected the users and/
or outputs and/or partials, you must set the base parameter, in other
words, whether at that time they are activated or deactivated.
In the figures to the side you can see the related screens:
0 = deactivation/block of partial/user/output
1 = activation/unblock if partial/user/output
- = no association
fig 1, turning off of partial one and arming of partial 2 was pro-
grammed.
Fig 2, activation of output 2 was programmed
Fig 3, block of user 1 was programmed
Once you have set the timers and created the weekly profiles, you can make it so the automatic action is suspended for a period of
time (e.g., for vacations, holidays, etc.)
The exclusion periods have a start and end date.
The beginning starts at 00:01 and the end at 23:59:59.
In the figure you can see that exclusion period no. 3 was programmed. This period starts at 00:01 on 10/02 and ends at 23:59:59
on 25/02
timerS menu: enABLe excLuSionS
After having set the exclusion period, it is activated by associating it to one or more timers.
The exclusion periods can be associated precisely to the individual timers (of the 8 available for each day of the week) Each timer
can have more than one period of exclusion.
In the figure you can see that at timer no. 2 for Monday, 2 exclusion periods were associated, no. 1 and no. 3.
[01] User Nr 01
0 - - - - - - - - - - - - - -
Period 03
10/02 < - - > 25/02
