American Dynamics Intellex User Manual

Basic Features
16 Intellex® Ultra
Playing Back Video Clips
1 Click the jog shuttle control or a VCR button to open playback mode.
2 Click a button to select a camera (its number) or cameras (1x1, 2x2, 3x3, 4x4).
3 Drag and drop the selected camera buttons to multi-screen panes.
4 Use the slider to approximate the player’s position.
5 Click the jog shuttle control or the VCR’s middle button to pause playback mode.
6 Click Close to exit playback mode.
Slider Control
VCR Control
Jog Shuttle Control
1 Click once to play back video.
2 Click again to pause video.
3 When playing, click and drag the arrow clockwise to increase playback speed or
counterclockwise to reduce or reverse playback speed. Click and drag the arrow horizontally to
the left or right to achieve the same results.
4 Continue dragging clockwise or counterclockwise to increase or decrease speed from 1–5
times normal speed. The speed increase or decrease appears.
5 When paused, click and drag the arrow clockwise to forward playback in slow motion or
counterclockwise to reverse playback in slow motion.
6 Continue dragging clockwise or counterclockwise to increase or decrease speed from 1–5
times slow motion speed. The speed increase or decrease appears.
Play, pause, or move through the video stream using the slider
and Play/Pause button.
Fast Reverse
• If you are fast forwarding, each click
decreases the speed up to 5 times
normal speed.
• If you are fast reversing, each click
increases the speed up to 5 times
normal speed.
Fast Forward
• If you are fast forwarding, each click
increases the speed up to 5 times
normal speed.
• If you are fast reversing, each click
decreases the speed up to 5 times
normal speed.
Play back Play
Step back or forward a single frame
Pause
