Advanced Features
32 Intellex® Ultra
Determining Minimum Object Size
Click Size to change the default size of an object. An object larger than the selected or default size
triggers the alarm.
Specifying an Object’s Direction
Direction arrows are 45° apart. When you enable multiple directions, you expand the directions in
which you track the object. To account for variations when searching in one direction, select more
than one arrow within the directional range.
Target area with a sizing object.
Drag its handles to change the
object’s size and aspect ratio.
Changes the minimum size of
an object that triggers an
alarm.
Preserves the
aspect ratio as
size is adjusted.
Click to activate direction arrows.
Click one or more arrows to activate (highlight)
or deactivate (gray out) a direction.
